Introdution

• The whole machine is centrally controlled by PLC system, 360 degree elec tric color registration（full-automatic computer automatic color registrat ion is optional），high-definition color still picturo monitoring whichis convenient for the observation of printing quality；
• The unwinding unit adopts single station structure：3+6” shaftle SS feeding mode:Automatic deviation correction and constant tension cont rol:Bquipped with refueling warning and paper break shutdown device：
• The whole machine is driven by high precision servo motor：
• Unwinding traction adopts double cots topress and feed paper,and the pressure is controlled by pneumatic componcnts:Thc tapcr control technolo gy is used to control the tension to ensure the color registration accurac yi
• Tho unwind adopts high powor corona machine for surfacc material treatm ont tostrengthen tho printing adhesion sothat the ink will not fade：
• The printing unit adopts ceramic mesh roller ink transfer,two way clos edink scraping mode, and the ink supply pump automatically supplies ink:Hydraulic clutch of mesh rollor and plate rollor,automatic separation aft or shutdown:The indepondent motor drives the mosh roller to prevent thei nk from solidifying on the surface of the mesh roller and blocking the mes hhole.
• The embossing die adopts high precision alloy abrasives,which has long service life andis not easy to be damaged：
• Theedgeiscontrolled by stainless steelframe,and the deptservice life andis not easy to be damaged；
• Theinserting edgeis controlled by stainless steel frame,and the dept h can be adjusted manually according to the product size；
• Therewinding traction adopts double cots topressand feed paper,and the pressureis controlledby pneumatic components；The taper control tech nology is used to control the tension to ensure the post overprint accurac y：
• Thematerial rewinding unit can adopt single workposition structure（fullyautomatic non-stopmaterialreceiving isoptional）：3“or6”inflata bleairshaftloadingmode；
• Drivenbymotor,withclosed-looptensioncont rol and paper breaking shutdown device.
• Independent drying system:builtininfraredwave heating drying（temp eratureadjustable）
